BLPC2-63 Precision Agile Open-Type Double-Point Battery Power Press is developed for high-speed stamping of small-format battery shells, with a nominal capacity of 630 kN. The double-point structure provides balanced force distribution across the slide, helping maintain dimensional consistency and forming stability in thin-wall battery case production. The machine operates at speeds of up to 80 strokes per minute and is equipped with a 1300 × 550 mm worktable, suitable for precision multi-station dies used in battery component manufacturing. A dry clutch-brake system ensures responsive engagement and stopping performance, while a hydraulic overload protection device enhances operational safety and protects tooling during continuous production.
| Basic data | BLPCⅡ-63 | BLPCⅡ-80 | BLPCⅡ-110 | |
| Model | V H | V H | V H | |
| Nominal Capacity | (kN) | 630 | 800 | 1100 |
| Nominal Pressure Stroke | (mm) | 5 | 5 | 5 |
| Strokes of Slide | (mm) | 140 | 180 | 190 |
| Strokes per Minute | (S.P.M) | 50-80 | 45-75 | 35-70 |
| Max. Die Height | (mm) | 280 | 320 | 480 |
| Die Height Adjustment | (mm) | 50 | 80 | 90 |
| Worktable Size | (mm) | 1300x550x120 | 1600x610x130 | 1970x680x130 |
| Slide Bottom Size | (mm) | 1200x500x70 | 1450x520x70 | 1800x580x70 |
| Side opening | (mm) | 250x120 | 300x140 | 320x180 |
| Throat depth | (mm) | 285 | 310 | 350 |
| Distance between Column | (mm) | 1000 | 1200 | 1550 |
| Height of working face | (mm) | 940 | 957 | 1085 |
| Max weight | (Kg) | 360 | 450 | 690 |
| Air Pressure | (MPa) | 0.55 | 0.55 | 0.55 |
| Power Supply | (V/Hz) | 3-phase 380V 50Hz | 3-phase 380V 50Hz | 3-phase 380V 50Hz |
| Main Motor | (kW*P) | (vs) 7.5*4 | (vs) 11*4 | (vs) 15*4 |
| 基本參數 Basic data | BLPCⅡ-63 | BLPCⅡ-80 | BLPCⅡ-110 | ||
| 型號 | Model | V H | V H | V H | |
| 公稱力 | Nominal Capacity | (kN) | 630 | 800 | 1100 |
| 公稱力行程 | Nominal Pressure Stroke | (mm) | 5 | 5 | 5 |
| 滑塊行程 | Strokes of Slide | (mm) | 140 | 180 | 190 |
| 滑塊行程次數 | Strokes per Minute | (S.P.M) | 50-80 | 45-75 | 35-70 |
| 最大裝模高度 | Max.Die Height | (mm) | 280 | 320 | 480 |
| 裝模高度調節量 | Die Height Adjustment | (mm) | 50 | 80 | 90 |
| 工作臺板尺寸 | Worktable Size | (mm) | 1300x550x120 | 1600x610x130 | 1970x680x130 |
| 滑塊底板尺寸 | Slide Bottom Size | (mm) | 1200x500x70 | 1450x520x70 | 1800x580x70 |
| 側面開口(左右上下) | Side opening | (mm) | 250x120 | 300x140 | 320x180 |
| 滑塊中心到機身距離 | Throat depth | (mm) | 285 | 310 | 350 |
| 立柱間距離 | Distance between Column | (mm) | 1000 | 1200 | 1550 |
| 工作臺離地面距離 | Height of working face | (mm) | 940 | 957 | 1085 |
| 最大上模重量 | Max weight | (Kg) | 360 | 450 | 690 |
| 使用空氣壓力 | Air Pressure | (MPa) | 0.55 | 0.55 | 0.55 |
| 電源 | Power Supply | (V/Hz) | 3相 380V 50Hz | 3相 380V 50Hz | 3相 380V 50Hz |
| 主電動機 | Main Motor | (kW*P) | (vs) 7.5*4 | (vs) 11*4 | (vs) 15*4 |
