BLPE-315 High-Capacity Heavy-Duty Closed-Type Double-Point Press

Home / Products / Closed-Type Power Press / Closed-Type Double-Point Press / BLPE-315 High-Capacity Heavy-Duty Closed-Type Double-Point Press

BLPE-315 High-Capacity Heavy-Duty Closed-Type Double-Point Press

BLPE-315 Industrial Powerhouse Closed-Type Double-Point Press provides a formidable 3150 kN of nominal force supported by a high-rigidity, three-section frame. Driven by a high-torque 30 kW main motor, this machine is engineered for the most demanding industrial stamping and forging tasks, featuring a 300 mm slide stroke V-type and a 615 mm maximum die height. The BLPE-315 Industrial Powerhouse Closed-Type Double-Point Press incorporates an advanced electric mode height display and an electric automatic lubrication system to ensure long-term durability in high-intensity environments. With its integrated photo-electronic safety device and highly sensitive control systems, this robust machine represents the ultimate choice for automotive and heavy appliance production lines requiring maximum tonnage and reliability.

Contact Us Contact Us
PREV：BLPE-250 Robust Wide-Bed Closed-Type Double-Point Press NEXT：No next product
  • Description
  • Contact Us
Basic data BLPE-160 BLPE-200 BLPE-250 BLPE-315 BLPE-400 BLPE-500 BLPE-630 BLPE-800 BLPE-1000 BLPE-1250
Model V H V H V H V H V H V H V H V H V H V H
Nominal Capacity (kN) 1600 2000 2500 3150 4000 5000 6300 8000 10000 12500
Nominal Pressure Stroke (mm) 6 3 6 3 7 3 7 3 9 3.5 9 3.5 10 5 13 9 13 9 13 9
Strokes of Slide (mm) 180 130 250 150 280 170 300 170 300 200 300 200 400 200 400 300 400 300 400 300
Strokes per Minute (S.P.M) 35-55 40-85 20-50 35-70 20-40 30-60 20-35 30-50 20-35 30-50 20-35 30-50 15-30 20-35 15-25 20-30 12-20 18-25 12-20 18-25
Max. Die Height (mm) 450 475 500 600 550 605 550 615 600 650 650 700 650 700 750 800 1000 1050 1000 1050
Die Height Adjustment (mm) 100 120 120 120 150 150 150 250
Worktable Size (mm) 1800x760x150 2200x940x170 2500x1000x170 2500x1000x190 2800x1000/3200x1100x200 3200x1200x220 3400x1300x250 3800x1600x260 4000x1800x280 4200x1800x300
Slide Bottom Size (mm) 1600x650x70 1850x750x95 2300x900x95 2300x900x95 2600x900/3000x1000x100 3000x1100x100 3200x1200x105 3800x1600x115 4000x1800x115 4200x1800x115
Distance between Column (mm) 1880 2290 2800 2800 3100 / 3300 3500 3700 4100 4200 4400
Height of working face (mm) 1000 1000 1100 1200 1430 1520 1550 1650 \
Side opening (mm) 700x450 900x600 900x600 900x600 900x600 1000x600 1000x600 1100x800 1200x900 1200x900
Main motor (kW*P) (vs) 15*4 (vs) 18.5*4 (vs) 22*4 (vs) 30*4 (vs) 37*4 (vs) 45*4 (vs) 55*4 (vs) 75*4 (vs) 110*4 (vs) 110*4
Die height adjuster (kW) 1.1 1.5 1.5 1.5 2.2 3.7 5 7.5
Air Pressure (MPa) 0.55
Punch accuracy \ GB(JIS)1 class
Overall Dimension (mm) 2309x2590x3682 2523x3000x3915 2799x3600x4593 2899x3600x4729 3129x4100x5257 3750x4300x5870 3900x4600x6100 \
Press Structure \ One-piece Integrated/Three-part Three-part
